4HSC Hydrogen Sulfide H2S Gas Sensor TBC Operating Principle 3-electrode electrochemical Sensitivity* 0.7 ± 0.15 μA/ppm

Model Number : 4HSC

MOQ : 1

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Delivery Time : 3-5 work days

Operating Principle : 3-electrode electrochemical

Measurement Range : 0-100 ppm

Maximum Overload : 500 ppm

Sensitivity* : 0.7 ± 0.15 μA/ppm

Response Time (T90)* : 20 Seconds at 20OC

Baseline Offset (clean air)* : < ±0.5 ppm equivalent

Zero Shift (-40°C to +50°C)* : < ±0.4 ppm equivalent

Contact Now

4HSC Hydrogen Sulfide (H2S) Gas Sensor Part Number: TBC Improved performance variability

Key Features & Benefits:

• Industry leading reliability
• Improved performance variability

Poisoning:
CiTiceLs are designed for operation in a wide range of environments and harsh conditions. However, it is
important that exposure to high concentrations of solvent vapours is avoided, both during storage, fitting into
instruments, and operation.
When using sensors with printed circuit boards (PCBs), degreasing agents should be used before the sensor is
fitted. Do not glue directly on or near the CiTiceL as the solvent may cause crazing of the plastic.

Repeatability *	< ±5%
Linearity*	Linear <±5%
Bias Voltage	Not required
Housing Material	Noryl 110
Weight	5 g (approx.)
Maximum at 500ppm	0.5 mA
Long Term Output Drift*	< 20% per annum
Recommended Storage Temp	10°C to +30°C

4HSC Hydrogen Sulfide H2S Gas Sensor TBC Operating Principle 3-electrode electrochemical Sensitivity* 0.7 ± 0.15 μA/ppm
